Is your Ford F150 heater not working? Don’t stress! I’ve got you covered.
In this article, I will discuss the potential reasons why the heater is not working on your truck and how you can troubleshoot and fix this problem.
The main reason might be the low coolant level in the reservoir – others include a bad fuse, bad relay, faulty blower motor, or blower motor resistor.
So without further ado, let’s dive into it.
Please Note: This guide applies to any Ford F150 truck, regardless of the model year.
Common years with this problem are Ford F150 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, and 2019.
7 Reasons Why Ford F150 Heater Not Working!
The main reasons why the Ford F150 heater is not working are:
| Problem | Solution |
|---|---|
| Blown blower motor fuse | Replace the fuse |
| Bad blower motor relay | Install a new relay |
| Faulty or stuck open thermostat | Replace the thermostat |
| Low coolant level | Refill the coolant within the cold fill range |
| Coolant flow restriction | Free the hose restriction |
| Clogged heater core | Flush the heater core |
| Faulty blower motor | Replace the blower motor |
| Faulty blower motor resistor | Replace the blower motor resistor |
1. Blown Fuse
First thing first, look for any blown fuses in the battery junction box under the hood.
Locate fuse number 51 (40 Amp) – the blower motor fuse. Look for any damages, and test it with a test light or a multimeter.
For quick verification, you can swap it with an identical one and check whether the heater is working.
If the swap fixes the heater, you need to replace the fuse to solve the problem.
2. Bad Relay
Next, you need to ensure that the relays are working properly, especially the blower motor relay.
First, find the appropriate relay position (usually number 3) that controls the blower motor and remove it from the box. Look for any physical damage or buildup that might cause the relay not to work properly.
If the relay has dirt, debris, or gunk, you must clean it up and install it back. Additionally, you can swap it with another relay from the box and check whether it fixes the problem.
In terms of a faulty, or damaged relay, you need to replace the relay to fix this heater problem on your Ford F150.
3. Stuck Open Thermostat
If the engine doesn’t reach the operating temperature after 15 to 20 minutes of running, you need to check whether the thermostat is working properly.
And if this continues to happen after 30 minutes of running the engine, the thermostat might be stuck open or faulty.
So, first, you need to replace the thermostat, and if there are no other problems, replacing the thermostat will fix the heater issue.
4. Low Coolant Level
This is the most common reason why the heater doesn’t work. And it might be the case for your truck as well.
To verify the low coolant level, open up the hood, and do a visual inspection to see whether the coolant reservoir has an adequate amount of coolant.
If the coolant level is low or the reservoir is completely empty, go ahead and refill the reservoir with appropriate coolant within the cold fill range when the engine is cold. And you should get the heater up and running again.
After filling up the coolant, if you see the problem still persists, you need to concentrate on the heater core, blower motor, and resistor.
5. Clogged Up Heater Core
If you have adequate coolant, yet there’s no heat, the heater core might be clogged up, or the coolant flow is restricted.
Look for any twister or pinched heater core hoses in the engine bay. If you find any, make sure you fix the coolant flow.
Now, the heater core can be clogged, and you can get an idea from the radiator. Open the radiator cap, and look inside.
If there is rust or debris in the radiator cap and inside the radiator, the heater core might also not be in good condition.
Additionally, you can measure the temperature difference between the two hoses with an infrared thermometer. If the difference is more than 30 to 35, the possibility of being clogged up is higher.
In this case, you need to flush the coolant system, or at least the heater core, to fix this problem.
6. Faulty Blower Motor
If the blower motor is faulty, you won’t get any hot air. So, make sure the blower motor is working properly.
To verify the motor, put the ignition key in the ON position, and turn on the heater switch. Get a test light, and check the voltage at the blower motor connector.
You can test them with a test light. Watch the following video for a better understanding.
If both the power and ground are fine, then the motor is faulty. In this case, you need to replace the blower motor, and the heater will be fixed.
7. Faulty Blower Motor Resistor
The blower motor is working properly? Alright, now, you need to verify whether the resistor is fine.
With a test light, check the voltage at the resistor connector. Test the power and ground with the test light and the signal wire with a multimeter. If all of them are fine, the resistor is faulty.
In this case, you need to replace the blower motor resistor to fix the heater problem on your Ford F150.
Final Words
I hope you have all the information on why the Ford F150 heater is not working. You can try all the troubleshooting methods I have discussed above, and hopefully, you’ll get the heater problem fixed.
I have a 2014 Ford F1 50 and the AC/heat and the lights that show where everything is for AC and heat is out. I have nothing here or AC. Can you tell me what the problem is? Is it a fuse or something else?
the heart/blower is working fine , the thermost tat is working , its the heat switch on the dasd between the blower switch and and the switxh for befrost bottom , the color on the heat swithch is red gor heat and blue for cool air , thats the switch thats not working please help
My air conditioner keeps running on my truck. Even when I turn the heater on so it doesn’t work right?
Ac runs with heater to perform a defrost function, so that is working fine. Its engineered that way
My 2016 f150 has the following problem.
1. windshield defrost is not working
2. dash panel and foot stays on when tey are turned off and defrost only is on, even though defrost will not blow any air.
I have a 2013 FX4 that has no heat in the cab. The heater core, the thermostat, relay, blower motor and anti-freeze has been replaced. The system has been flushed twice. According to the Ford dealership, which I trust, there is air getting injected into the coolant lines. The inward line to the heater core reads 190 at operating temp. Which is exactly the thermostat rating. The outward line from the heater core reads 100 from the heater core and you can feel a foamy combination air and anti-freeze. I’m stumped as to how the air is getting in. My next move is a head gasket, maybe. Any thoughts. Thanks
Just a thought, not an expert. The motor coolant system may need to be burped! If air is suspect. Look for the a high spot in the coolant system and try to add coolant at a nearby fitting or connection. There may be two high places that need coolant to fill the air gaps. This once was a common as designed problem, requiring a fill, run, check, fill, repeat process… not fun once coolant was hot.
Good Luck from SE Michigan
Blower fan only works on high speed, no other position works.
